FLANGES
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
RANGE : 15 NB UP TO 600 NB IN 150 LBS , 300 LBS, 400 LBS , 600 LBS , 900 LBS , 1500 LBS , 2500 LBS / TABLE 2.5 , TABLE 6 , TABLE 10, TABLE 16,TABLE 25 , TABLE 40, TABLE 64, TABLE 160, TABLE 320, TABLE 400
GRADE : 304,304L,304H, 316, 316L, 310, 310S, 904L, 347, 347H, 317L, 410 409, 420, 630 etc.
CLASS : 150#, 300#, 600#, 900#, 1500# & 2500#
STANDARD: ANSI, JIS, DIN, EN1092-1, UNI, BS4504, SABS1123, AS2129, GOST-12820
DIMENSION: ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44
MATERIAL: ASTM A105, ASME A105, ASTM A266 GR.1, GR.2, GR.3, GR.4ASTM A350 LF1, LF2 CL1/CL2, LF3 CL1/CL2, ASTM A694 F42, F46, F48, F50, F52, F56, F60, F65, F70
WALL THICKNESS: SCH.10, 20, 30, 40, 80, 120, 160, STD, XS, XXS.
FORM: Slip on Flanges – SORF, Weld Neck Flanges – WNRF, Socket Weld Flanges – SWRF, Blind Flanges – BLRF Lapped joint Flanges, Screwed Flanges, Long weld neck Flanges, Reducing Flanges, Spectacle Flanges, Ring joint Flanges
SLIP ON FLANGE
BLIND FLANGE
WELD NECK FLANGE
LONG WELD NECK FLANGE
FORGED FITTINGS
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
RANGE : 15 NB UP TO 100 NB IN 2000 LBS , 3000 LBS , 6000 LBS & 9000 LBS , 150 LBS , 250 LBS.
GRADE : 304,304L,304H, 316, 316L, 310, 310S, 904L, 347, 347H, 317L, 410 409, 420, 630 etc.
CLASS : 3000LBS, 6000LBS, 9000LBS
90 DEGREE ELBOW
SQUARE HEAD PLUG
.jpeg)
45 DEGREE ELBOW
HEXAGON PLUG
TEE
TYPE 2 REDUCER INSERTS
LONG COUPLING
TYPE 1 REDUCER INSERT
BUTTWELD FITTINGS
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
RANGE : 15 NB UP TO 1200 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS.
GRADE : 304 , 304L ,304H, 304N , 304LN , 309, 310H , 316 , 316H , 317 , 317L , 321 , 321H , 347 , 347 H, 630 etc.
CLASS : 3000LBS, 6000LBS, 9000LBS
.jpeg)
SS PIPE REDUCER
ELBOW
TEES
MS PIPE REDUCER
PLATES & SHEETS
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
RANGE : 0.1 mm to 100 mm thick upto 2500 mm width & upto 8000 mm length
GRADE : 304 , 304L , 304H, 309S , 309H, 310S , 310H , 316 , 316H , 316L , 316 TI , 317 , 317L , 321 , 321H , 347 , 347 H , 409 , 410 , 410S , 430, etc
CLASS : 3000LBS, 6000LBS, 9000LBS
FASTENERS
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
SIZE : M5 TO M50
GRADE : FASTENERS-AISI 202, 304, 304L,316, 316L, 310, 410, 420 Etc. 4.6 , 5.6, 6.6, 8.8, 10.9 & 12.9 / 'R', 'S', 'T' Conditions
TYPES : Bolts Stud Bolts, Hex Head Bolts, Socket Hexagon Head Screw Anchor Bolts, U-Bolts, J Bolts, Mushroom Head Square Neck Bolts , T- Head Bolts , Wing Screw , Eye Bolt , Eye Bolt, Foundation Bolts, Structural Bolts.
PIPES
DUPLEX & STAINLESS STEEL, CARBON & ALLOY, NICKEL & COPPER ALLOY, HASTELLOY, ICONEL, INCOLOY, MONEL AND TITANIUM
RANGE : 15 NB UP TO 1200 NB IN SCH 5S , 10S ,10, 20 , 40S , 40 , STD , 60 , 80S , 80 , XS , 100 , 120 , 140 , 160 & XXS.
GRADE : 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316TI , 316H , 316 LN , 317 , 317L , 321 , 321H , 347 , 347 H , 904L .
ASTM / ASME SA 358 CL 1 & CL 3 GR . 304 , 304L , 304H, 309S ,309H , 310S, 310H , 316 , 316H , 321 , 321H , 347 .
GASKETS
RANGE : ½" to 3½" dia. Wide range of length.
GRADE : B7/2H, B7M/2hm & L7/4 L7M/7M Stainless Steel.
BOLT TYPES : Fully and partially Threaded Stud bolt complete with nuts.
GASKETS : Spiral Wound, Ring Joint, Tanged insert, PTFE Products, Rubber Sheets.
VALVES
RANGE : ½" to 48" - 150 lb to 2500 lb Flanged, NPT, SW, BW Connections
BALL: Floating & Trunnion Execution Split body, Top Entry, Side Entry, Fully Welded.
STANDARD: BS5351, AP16D and API6A
GATE, GLOBE, CHECK : Forged & Cast Execution
MATERIAL & GRADES : A105N, WCB, WCC, LF2, LCB, LCC, F316L, F304L, F321, CF8, CF8C, CF8M, F5, F9, F11, F51, F53
SPECIAL : Metal Seated Valves, Cryogenic Valves, Actuated Valves, Exotic Alloy Valves
COATING : Polythene, Epoxy, Cement Lining
OPERATING : Lo, Go Hydraulic Electric Movement
